Drive Axle for Forklifts

Drive Axle for Forklift - The piece of machinery which is elastically fastened to the framework of the vehicle utilizing a lift mast is referred to as the forklift drive axle. The lift mast connects to the drive axle and can be inclined, by no less than one tilting cylinder, around the axial centerline of the drive axle. Frontward bearing parts together with back bearing elements of a torque bearing system are responsible for fastening the vehicle and the drive axle framework. The drive axle could be pivoted around a swiveling axis oriented transversely and horizontally in the vicinity of the rear bearing elements. The lift mast is likewise capable of being inclined relative to the drive axle. The tilting cylinder is connected to the vehicle frame and the lift mast in an articulated fashion. This allows the tilting cylinder to be oriented almost parallel to a plane extending from the axial centerline and to the swiveling axis.

Lift truck units like H35, H40 and H45 that are produced in Aschaffenburg, Germany by Linde AG, have the lift mast tilt ably affixedconnected on the vehicle frame. The drive axle is elastically connected to the forklift frame utilizing numerous bearing devices. The drive axle has tubular axle body along with extension arms affixed to it and extend backwards. This particular kind of drive axle is elastically attached to the vehicle framework using rear bearing elements on the extension arms along with frontward bearing devices located on the axle body. There are two back and two front bearing tools. Each one is separated in the transverse direction of the lift truck from the other bearing device in its respective pair.

The braking and drive torques of the drive axle are sustained through the back bearing components on the frame utilizing the extension arms. The load and the lift mast produce the forces which are transmitted into the roadway or floor by the framework of the vehicle through the drive axle's front bearing components. It is essential to make sure the elements of the drive axle are constructed in a firm enough manner to maintain stability of the lift truck truck. The bearing components can lessen small road surface irregularities or bumps during travel to a limited extent and offer a bit smoother operation.
